Prestige Multipurpose Soft Closing Square Waste Chute 220mm

£159.60 £133.00
SKU
AD-KH020-HL
In stock
Warranty :
10 years
Delivery :
Next Working Day
  • Material: Type 304 Stainless Steel
  • Finished in Brushed Satin
  • Soft Close Mechanism
  • Lid Dimensions (mm): 220mm x 220mm

Prestige 220mm Multipurpose Soft Closing Square Waste Chute



The Sugatsune AD‑KH020‑HL is a high-performance, soft-close multipurpose lid, expertly crafted from premium 304 stainless steel with a sleek satin brushed finish. Designed for applications such as countertop waste chutes, trash openings, and linen disposals, this lid combines durability with refined functionality. Its integrated damper mechanism ensures a smooth, quiet closure by preventing slamming, making it ideal for both commercial and architectural environments.

With dimensions of 220mm x 220mm, a 1.2mm thick lid, and a total height of 50mm, the unit features a balance-weighted hinge that automatically returns the lid to a horizontal position after use.

The soft-close mechanism operates effectively in ambient temperatures ranging from 0°C to 40°C (32°F to 104°F), providing reliable, silent performance. Designed for overhead installation and weighing approximately 1.4kg, the AD‑KH020‑HL offers a seamless blend of aesthetics, hygiene, and engineered precision for high-traffic or design-conscious installations.



  • Material: Type 304 Stainless Steel
  • Finished in Brushed Satin
  • Soft Close Mechanism
  • 100% Plastic Free Packaging
  • Lid Dimensions (mm): 220mm x 220mm
  • Height (mm): 50mm
  • Thickness: 1.2mm
  • Temperature Range: 0°C and 40°C
  • Internal Measurements: 196mm x 196mm
  • Soft Rounded Corners
  • Cut Out Size: 197mm x 197mm
  • GTIN/EAN: 4510932178167

SKU AD-KH020-HL
Finish Brushed Satin Stainless Steel
Height (mm) 50mm
Outer Dimensions (mm) 220mm x 220mm
Inside Dimensions (mm) 196mm  x 196mm
Waste Disposal area (cm2) 24.3 (135mm x 180mm)
Hole Cut out Diameter (mm) 197mm - 197mm
Steel Gauge (mm) 1.2mm
Installation Counter Tops Only
Mechanism Operating Temperatures (C) 0 - 40℃
Steel Type Type 304
Weight (kg) 1.4kg
GTIN/EAN 4510932178167









What are the dimensions of the flap lid?

The flap lid measures 220mm x 220mm with a height of 50mm and a stainless steel thickness of 1.2mm.



Can it be installed horizontally in a countertop?

Yes, it is designed specifically for overhead or horizontal surface installation, such as on countertops, waste chutes, or transfer openings.



What temperature range can the lid operate in?

The product functions reliably in environments ranging from 0°C to 40°C.



What materials is the AD‑KH020‑HL made from?

The lid is made from high-quality AISI 304 stainless steel, offering excellent corrosion resistance and durability, ideal for hygiene-sensitive environments.



Does the flap close automatically?

Yes, the lid features a built-in soft-close damper and an automatic return mechanism that ensures it closes smoothly and quietly after use.

More Information
SKUAD-KH020-HL
GTIN4510932178167
Weight1.400000
Warranty10 years
Quick Code4039
ManufacturerPrestige
DeliveryNext Working Day
